Fluid Bed Dryer Manufacturer And Supplier In UAE
Fluid Bed Dryers Details
Technogen Enterprise provides advanced Fluid Bed Dryers engineered for high‑efficiency drying across pharmaceutical, food, chemical, herbal and cosmetic sectors in the UAE. Designed in compliance with cGMP standards and built with precision stainless‑steel construction, these dryers deliver uniform drying, energy efficiency and process reliability for industrial hubs including Dubai, Abu Dhabi, Sharjah, Ajman, Ras Al Khaimah, Fujairah and Umm Al Quwain.
Overview
A Fluid Bed Dryer is a high‑performance drying system that uses controlled hot air to fluidize and dry powders, granules and heat‑sensitive materials. Its uniform air distribution ensures consistent moisture removal, enhanced product purity and reduced processing time, making it suitable for regulated industries across the UAE’s rapidly growing manufacturing landscape.
Working Principle
A stream of filtered, heated air enters the product chamber and passes through a perforated plate. When the air velocity reaches an optimal level, the product becomes suspended, forming a fluidized state. This results in intensive heat transfer and rapid moisture evaporation. Once the target dryness level is achieved, material is discharged using an integrated lifting and tilting mechanism.
Key Process Characteristics
Uniform contact between air and particles
Short drying cycles
Precision moisture control
Minimal material handling
Enhanced hygiene and safety
Process Flow
Loading of wet granules or powders into the product container
Fresh air intake, filtration and controlled heating
Formation of fluidized state through even air distribution
Moisture removal through constant hot air circulation
Discharge via container tilting or automated mechanism
Core Features
cGMP‑compliant hygienic design
Rigid modular stainless‑steel construction (SS304/316/316L)
Quiet and efficient blower system
Rapid and uniform drying across the batch
Integrated lifting and tilting system
Manual and PLC‑based automation options
Wide capacity range from 5 kg to 500 kg
Optional Integrations
Online batch sampling
Pneumatic shaking
Flame‑proof (FLP) safety design
Custom electrical configurations
Technical Specifications
| Model | TGFBD-30 | TGFBD-60 | TGFBD-120 |
|---|---|---|---|
| Batch Size (kg) | 25 – 30 | 50 – 60 | 100 – 120 |
| Container Volume (kg) | 71 | 142 | 288 |
| Air Flow | 706 | 1059 | 1882 |
| Air Flow (m³/hr) | 1200 | 1800 | 3200 |
| Static Pressure (mm of water) | 600 | 600 | 800 |
| Electrical Heater (kW) | 20 | 36 | – |
| Drying Temperature (°C) | 45 – 80 | 45 – 80 | 45 – 80 |
| Steam Pressure (kg/cm²) | 3.5 | 3.5 | 3.5 |
| Steam Consumption (kg/hr) | 50 | 72 | 144 |
| Blower Motor | 7.5 HP, 3 Phase | 10 HP, 3 Phase | 15 HP, 3 Phase |
Applications
Pharmaceutical Industry
Drying granules for tablet and capsule production
Achieving precise moisture content for formulation stability
Food Industry
Drying spices, grains and powdered additives
Maintaining texture, color and nutrient profile
Chemical Industry
Drying resins, polymers and specialty powders
Ensuring stable downstream processing
Herbal Industry
Drying extracts and herbal powders
Protecting therapeutic components during processing
Cosmetic Industry
Drying fillers, powders and cosmetic ingredients
Supporting uniform product consistency
Technical Benefits for UAE Industry
Fast and even moisture removal
Reduced energy consumption through optimized airflow
Safe operation with optional flame‑proof design
Quick dismantling for cleaning and validation
Scalability for laboratory, pilot and bulk production
Automation possibilities with PLC‑SCADA control
Why Technogen Enterprise
Technogen Enterprise is a leading manufacturer and supplier delivering high‑precision Fluid Bed Dryers to UAE industrial sectors. Each machine is engineered for durability, process accuracy and compliance with international quality standards including cGMP, FDA and ISO.
Strengths
Advanced design and precision engineering
Strict global quality compliance
Custom‑configured equipment for unique processes
Strong global supply network covering Asia, Africa, Europe and the Middle East
Dedicated installation, maintenance and operator training support
Export Capability
Each Fluid Bed Dryer is produced under stringent quality controls, securely packaged for international logistics and aligned with global safety and performance standards. Technogen Enterprise serves major industrial clients across UAE’s key production zones and free‑trade hubs.
Supporting UAE’s Industrial Growth
Technogen Fluid Bed Dryers support efficient, hygienic and consistent drying required by UAE’s pharmaceutical manufacturing units, food processing plants, chemical factories, herbal formulation units and cosmetic producers. The technology ensures product uniformity, operational reliability and regulatory adherence across diverse production environments.
